AC Infinity

AC Infinity Airplate T8

Order Within

—

Province

Est. Delivery

—

$0.00

Ontario

$125.00

Canada

$149.99

Qualifies for Free Shipping Promotion

Description

超静音双风扇系统设计用于冷却家庭影院、娱乐中心和音视频柜。该套件包括两个独立风扇单元，一个排气扇和一个进气扇，以及一个温控器。每个风扇都采用定制电机，旨在最大程度地降低调速过程中的噪音，并获得了CE和RoHS认证。包含符合UL-507安全标准的AC Infinity轴流风扇ACX-FD1225(B)05W5，该标准由美国保险商实验室证书E503903认证。该设备采用额定寿命为67,000小时的双滚珠轴承，可以朝任何方向安装。它具有数控加工的铝制框架和现代拉丝黑色表面。风扇设置为向外排气，但可以使用螺丝刀将其反转以吸入空气。包括所有必要的硬件，可轻松将设备安装到柜子上并通过标准墙壁插座供电。

规格：长度：6.30英寸；宽度：6.30英寸；高度：1.30英寸；背面宽度：4.88英寸；背面长度：4.88英寸；线缆长度：6英尺；控制器长度：5.20英寸；控制器高度：3.11英寸；控制器宽度：1.10英寸；控制器背面长度：4.41英寸；控制器背面宽度：2.76英寸；显示屏尺寸：2.25 x 1.25英寸；显示屏：数字；控制设置：6；传感器探头长度：72英寸；颜色：拉丝黑色；噪音：19分贝；静压：1毫米水柱；工作电压：3 - 7直流伏特；功耗：3.3瓦；耗电量：0.66安培；总气流：104立方英尺/分钟；输入电压：100 - 240交流伏特；工作湿度：35 - 85%；工作温度：-17 - 70 °C；轴承：双滚珠轴承；额定寿命：67,000小时；包装内含：风扇：2个；控制器：1个；电源线：1根。

Warnings & Safety

Electrical Safety

Use this product only as directed in the manufacturer instructions. Connect only to a suitable outlet and correct voltage. Do not use if the cord, plug, housing, or adapter is damaged.

Water & Moisture Safety

Keep electrical parts, plugs, outlets, and controls away from water and moisture unless the product is specifically rated for wet or damp locations. Do not handle plugs or electrical parts with wet hands.

Power Load Safety

Do not overload outlets, timers, power bars, extension cords, or circuits. Use only properly rated accessories and follow the manufacturer’s wattage, amperage, and installation limits.

Ventilation & Heat Safety

Allow proper ventilation during use. Do not cover the product or block vents, fans, drivers, adapters, or heat sinks. Keep away from flammable materials and follow clearance requirements in the manual.

Cleaning & Service Safety

Unplug the product before cleaning, moving, installing, or servicing. Do not open, modify, or repair electrical components unless the manufacturer instructions specifically allow it.

Label & Manufacturer Directions

Always follow the official product label, package directions, and manufacturer safety information. Check the manufacturer website or official product documentation for the most complete and current usage, safety, storage, and disposal details. This notice is general guidance and does not replace the product label.

Specifications

Length	6.30 Inch
Width	6.30 Inch
Height	1.30 Inch
Backside Width	4.88 Inch
Backside Length	4.88 Inch
Cord Length	6Feet
Controller Length	5.20 Inch
Controller Height	3.11 Inch
Controller Width	1.10 Inch
Controller Backside Length	4.41 Inch
Controller Backside Width	2.76 Inch
Display Size	2.25 x 1.25 Inch
Display	Digital
Control Settings	6
Sensor Probe Length	72 Inch
Color	Brushed Black
Noise	19 dBA
Static Pressure	1 mm-H2O
Operating Voltage	3 - 7 DC Volts
Consumption Wattage	3.3 Watt
Consumption Amperage	0.66 A
Total Airflow	104 CFM
Input Voltage	100 - 240 AC Volts
Operating Humidity	35 - 85%
Operating Temperature	-17 - 70 °C
Bearings	Dual Ball Bearing
Rated Life	67,000 Hours

Inside The Box
Fans	2
Controllers	1
Power Cords	1
